Zip it into the bag, chuck it in the van, or toss it over the tailgate—when you get to the trails, you’ll be happy you’re on a Nomad. The refined suspension offers efficient climbing, less reactivity under braking, and improves traction everywhere in between. In short, you’ll be more comfortable, more composed, and more confident no matter what the trail throws your way.

• Carbon CC Frame
• RockShox Zeb Fork
• RockShox Super Deluxe Select Shock
• Shimano Deore M7200 Drivetrain

Frame
Weight
35.63 lbs / 16.16 kg

Suspension
Fork
RockShox Zeb Base, 170mm
Shock
RockShox Super Deluxe Select, 230x65

Drivetrain
Bottom Bracket
Shimano MT501 68/73mm Threaded
Cassette
Shimano Deore M6200, 10-51t
Chain
Shimano Deore M6100, 12spd
Chainguide
OneUp Chainguide
Crankset
Shimano Deore M6200, 32t S: 165mm, M-XXL: 170mm
Rear Derailleur
Shimano Deore M7200, 12spd
Right Shifter
Shimano Deore M6200, 12spd w/ Wolf Tooth Shiftmount Adapter for MM

Brakes
Brakes
SRAM DB8
Front Rotor
SRAM Centerline, 200mm
Rear Rotor
SRAM Centerline, 200mm

Cockpit
Grips / Bar Tape
Santa Cruz Bicycles House Grips
Handlebars
Burgtec Aluminum Bar, 35mm S: 760mm, 20mm Rise, M-XXL: 800mm, 30mm Rise
Headset
FSA IS-2/47/42 ACB
Saddle
SDG Bel-Air V3 Steel
Seatpost
SDG Tellis Dropper, 31.6 S: 125mm, M: 150mm, L: 170mm, XL-XXL: 200mm
Stem
OneUp Enduro Stem All Sizes: 42mm

Wheels
Front Rim
Reserve 30|TR AL
Front Hub
Shimano TC500, 15x110, 6-Bolt
Front Tire
Maxxis High Roller, 29"x2.4", 3C MaxxGrip, EXO+
Rear Rim
Reserve 30|HD AL
Rear Hub
Shimano TC600, 12x148, MicroSpline, 6-Bolt
Rear Tire
Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, Double Down
Valves
Reserve Fillmore Valves

Specs
Headset
Integrated (IS41/52)
Fork Axle to Crown
588mm
Fork Offset
44
Fork Compatibility
170-180mm
Suspension System
VPP™
Rear Travel
170mm
Recommended Sag
30%
Shock Length
230mm
Shock Stroke
65mm
Shock Bushing Size Front
30x8
Shock Bushing Size Rear
30x8
Bottom Bracket Shell
73mm Threaded
Chainline
55mm
Max Chainring Size
36t
Chainguide Standard
Integrated upper guide+2-bolt ISCG 05 bash mount
UDH Compatible
Yes
Rear Spacing
148mm
Rear Brake Mount
Postmount 200mm
Max Rotor Size
223mm
Seat Post Diameter
31.6
Seat Clamp Diameter
36.4
Water Bottle Mounts
1
Downtube Storage
Glovebox
